AD-761XLS Compression Driver – High-Powered

The AD-761XLS Compression Driver – High-Powered compression driver designed to deliver powerful, crystal-clear audio across a wide frequency spectrum. It features 140W RMS power capacity and handles up to 280W program power, making it ideal for professional audio systems that require exceptional clarity, high output, and long-term reliability.

Whether used in touring rigs, concert venues, houses of worship, or fixed installations, the AD-761XLS offers an ideal balance of performance, durability, and versatility.

At the heart of the AD-761XLS is a 72.5mm (3-inch) CCAW voice coil, designed for optimal thermal conductivity and efficiency. It ensures reliable performance even during extended periods of high-volume use. With a sensitivity rating of 108 ± 2dB, the driver efficiently converts power into sound pressure, making it ideal for environments where sound projection and articulation are critical.

The frequency response of 800Hz to 20,000Hz covers a wide range of high-frequency audio, capturing the finest details in vocals, instruments, and ambient effects. This makes the AD-761XLS an excellent choice for high-definition sound reproduction in both live and studio environments.

Constructed with a composite diaphragm, the driver delivers accurate transient response and smooth tonal characteristics while minimizing distortion. Its Strontium Ferrite Y35 magnet provides consistent magnetic force, ensuring a stable audio output across the entire frequency range.

Installation is quick and secure thanks to the 50mm (2-inch) throat diameter and bolt-on mounting design. This setup ensures broad compatibility with many horn flares and waveguides. The 170mm overall diameter and 4.9 kg net weight provide a solid, road-ready build. The AD-761XLS is durable enough for touring and compact enough for permanent installations.

Whether you’re upgrading an existing PA system or building a new high-performance rig from the ground up, the AD-761XLS provides the perfect combination of power, precision, and efficiency for superior sound delivery. It’s the go-to choice for professionals who demand both sound clarity and mechanical reliability.

Frequently Asked Questions (FAQs)

1. What is the power handling capacity of the AD-761XLS Compression Driver?

Answer: The AD-761XLS offers 140W RMS power handling and up to 280W program power, making it ideal for professional PA systems, concert venues, touring rigs, and high-output audio installations.

2. What frequency range does the AD-761XLS cover?

Answer: The AD-761XLS provides a wide frequency response of 800Hz to 20,000Hz, ensuring excellent reproduction of vocals, instruments, and high-frequency details with clarity and precision.

3. What type of magnet is used in the AD-761XLS?

Answer: The driver utilizes a Strontium Ferrite Y35 magnet, offering strong magnetic performance, reliable output stability, and long-term durability in demanding audio applications.

4. What is the sensitivity rating of the AD-761XLS?

Answer: The AD-761XLS features a high sensitivity rating of 108 ± 2dB, allowing it to deliver powerful sound pressure levels with efficient amplifier usage.

5. Is the AD-761XLS suitable for professional sound reinforcement systems?

Answer: Yes. The AD-761XLS is designed for concert sound systems, line arrays, houses of worship, auditoriums, rental companies, touring applications, and fixed installations where high-quality audio performance is required.

6. What type of voice coil is used in the AD-761XLS?

Answer: The driver is equipped with a 72.5mm (3-inch) CCAW (Copper Clad Aluminum Wire) voice coil, which provides excellent thermal efficiency, reduced moving mass, and consistent high-output performance.

7. What diaphragm material is used in the AD-761XLS?

Answer: The AD-761XLS features a composite diaphragm, engineered to provide accurate sound reproduction, smooth frequency response, and excellent durability under continuous operation.

8. What are the mounting specifications of the AD-761XLS?

Answer: The driver includes a 50mm (2-inch) throat diameter and a bolt-on mounting design, ensuring compatibility with a wide variety of professional horns, waveguides, and speaker enclosures.

9. Why is the AD-761XLS a good choice for live events and touring systems?

Answer: With its high sensitivity, powerful RMS handling, durable ferrite magnet structure, wide frequency response, and rugged construction, the AD-761XLS delivers reliable performance in demanding live sound environments.

10. What are the main benefits of choosing the AD-761XLS Compression Driver?

Answer: The AD-761XLS offers high output capability, exceptional vocal clarity, efficient power conversion, durable construction, broad system compatibility, and professional-grade reliability, making it a trusted choice for audio professionals.

Bonus FAQ

11. Can the AD-761XLS be used in both portable and permanent sound systems?

Answer: Yes. The AD-761XLS is suitable for both portable touring systems and fixed installations, thanks to its rugged construction, reliable performance, and versatile mounting compatibility.

12. How does the AD-761XLS improve sound quality in a speaker system?

Answer: The combination of a high-efficiency CCAW voice coil, composite diaphragm, and ferrite magnet technology allows the AD-761XLS to reproduce high frequencies with greater clarity, detail, and consistency while minimizing distortion.
