AD-7207 Professional 2-Inch Compression Driver

The AD-7207 Professional 2-Inch Compression Driver throat compression driver engineered for exceptional high-frequency sound reproduction in professional audio systems. With a robust 72.5mm (3-inch) copper-clad aluminum (CCAW) voice coil, this driver is capable of handling 120W RMS power and up to 240W program power, making it ideal for large-scale PA setups, concert arrays, and fixed installations that demand both clarity and power.

This unit delivers a high sensitivity of 108 ± 2dB, ensuring outstanding output with minimal power input. Whether it’s crisp vocals, detailed instrumentation, or impactful high-end audio, the AD-7207 ensures your sound system cuts through the mix with authority and precision.

Covering a wide frequency response range from 800Hz to 20,000Hz, the AD-7207 is capable of reproducing a broad spectrum of high frequencies with accuracy. This makes it particularly effective in applications requiring detailed top-end definition, such as professional stage monitors, line arrays, and horn-loaded high-frequency cabinets.

The diaphragm is made of titanium, a material known for its strength, lightweight properties, and resistance to fatigue—ensuring long-lasting performance even under demanding conditions. Paired with a Strontium Ferrite Y35 magnet, this driver generates a powerful magnetic flux for enhanced dynamic range and stable performance across the entire frequency band.

Installation is simple thanks to the 50mm (2-inch) throat diameter and bolt-on mounting type. This design ensures broad compatibility with various horn flares and enclosures. The AD-7207 has a compact 170mm overall diameter and weighs 4.65 kg. Its sturdy build offers excellent structural integrity, making it ideal for both mobile setups and fixed installations.

Whether you’re building a premium sound system or upgrading your existing rig, the AD-7207 compression driver offers an ideal combination of power, precision, and reliability, making it a go-to solution for audio professionals looking for top-tier performance in high-frequency applications.

Frequently Asked Questions (FAQs)

Q1. Audiotone AD-7207 compression driver kis tarah ke sound cabinets ke liye best suitable hai?

A: Yeh driver high-power 2-way speaker tops, line array modules, aur stage monitors ke liye design kiya gaya hai, jahan clear vocal throw aur high-frequency details ki requirement hoti hai.

Q2. Titanium diaphragm material ka sound performance par kya benefit hota hai?

A: Titanium diaphragm extreme rigidity aur high transient response provide karta hai, jisse high volume par bhi crispness aur HF distortion-free response maintain rehti hai.

Q3. CCAW voice coil aur Y35 Ferrite magnet se driver ki performance par kya effect padta hai?

A: Lightweight CCAW voice coil rapid movement allow karti hai aur Y35 Strontium Ferrite magnet continuous magnetic flux assure karta hai, jisse 108dB ki high sensitivity achieve hoti hai.

Q4. AD-7207 driver ko cabinet flare ke saath mount karne ke liye konsa throat size chaiye?

A: Isme standard 50 mm / 2-inch throat diameter diya gaya hai jo 2-inch bolt-on horn flares ke saath perfect fit hota hai.

Q5. Continuous touring aur live performance ke liye konsa crossover frequency setup ideal hai?

A: Driver ki 800Hz~20000Hz frequency response curve ke according 1.2kHz se 1.5kHz ke beech active/passive crossover cutoff set karna long life aur optimal balance ke liye recommended hai.
