AD-12X201FG – 12-Inch Copper Voice Coil Woofer

The AD-12X201FG – 12-Inch Copper Voice Coil Woofer woofer designed to deliver powerful sound output, clear audio reproduction, and long-lasting reliability. Engineered for optimal performance in a wide range of audio setups, it is the perfect solution for stage monitors, DJ systems, portable PA setups, and fixed installations that demand clarity, strength, and consistency.

With a nominal RMS power rating of 200W and a peak continuous power handling of 400W, this woofer ensures dependable output during extended use. Its 2″ (55.5mm) copper voice coil provides excellent heat resistance and conductivity, resulting in stable operation under high loads. The 97 ± 2dB sensitivity guarantees high sound output while maintaining excellent efficiency, making it ideal for setups where volume and clarity are critical.

Great observation. Here’s a revised version of that paragraph with simpler sentence structure, improved clarity, and SEO-friendly phrasing:

At its core, the AD-12X201FG features a Y35-grade ferrite magnet (156×70×20). It generates a strong magnetic field that ensures consistent, distortion-free performance. The magnet structure allows for smooth cone movement and efficient energy conversion. This helps the woofer handle sudden sound peaks with ease. A metal basket provides extra strength and stability. It also improves heat dissipation, making the woofer reliable during long hours of high-volume use.

With a nominal impedance of 4 ohms and DC resistance of 3.6 ohms, the woofer is compatible with most professional audio amplifiers and crossover setups. Weighing just 3.5 kg, it is lightweight and easy to install in a variety of cabinets or portable sound systems.

Frequently Asked Questions (FAQs)

Q1. Audiotone AD-12X201FG transducer ki power handling rating kya hai?

A: AD-12X201FG continuous 200 Watts RMS power handle karta hai aur 400 Watts Continuous Max power loading support karta hai.

Q2. Is 12-inch mid-bass transducer me voice coil aur magnet specs kya diye gaye hain?

A: Isme 2-inch (55.5mm) Copper (CU) voice coil aur Y35 high-grade 156x70x20 mm ferrite magnet structure install hai.

Q3. Frequency bandwidth, sensitivity, aur impedance ratings kya hain?

A: Transducer 45Hz se 4500Hz frequency response cover karta hai, 97 ± 2dB sensitivity offer karta hai, aur iska nominal impedance 4 Ω (DC resistance 3.6 Ω) hai.

Q4. AD-12X201FG kis type ke speaker enclosures ke liye ideal hai?

A: Yeh transducer compact 2-way full-range speaker boxes, stage monitors, aur DJ top cabinets me clear vocals aur punchy mid-bass frequencies deliver karne ke liye best hai.

Q5. Frame basket material aur overall weight details kya hain?

A: Unit me durable metal basket frame diya gaya hai aur iska net weight 3.5 kg hai, jo portable speaker cabinets ke liye lightweight option hai.
